Aiko 800 x 240mm 230V Milling & Drilling Machine | Model : ZAY7040A/1 - Aikchinhin

Aiko 800 x 240mm 230V Milling & Drilling Machine | Model : ZAY7040A/1

Regular price
$4,500.00
Sale price
$4,314.24
Tax included. Shipping calculated at checkout.

Features :

  • Table Size : 800 x 240mm
  • Power : Single Phase
  • Step speed changed cyclically and spindle auto-feeding and cyclic change of feeding speed
  • Milling, Drilling, Tapping, Boring and Reaming
  • Head swivels plus/minus 45 degrees vertically
  • Spindle micro feed precision
  • Adjustable gibs on table precision
  • Accurate position, strong rigidity, powerful cutting
  • Gear-driven type and square column

Standard Accessories :

  • Drill Chuck and arbor
  • Draw Bar
  • Allen keys
  • Wedge
  • Tool Box with tools

Specifications :

  • Max. Drilling Capacity : 40mm
  • Max. Face Milling Capacity : 80mm
  • Max. end Milling Capacity : 32mm
  • Max. Distance from spindle nose to table : 450mm
  • Min. Distance from spindle axis to column : 260mm
  • Spindle Travel : 130mm
  • Spindle Taper : MT3, MT4, R8
  • Step of spindle speed : 6 Steps
  • Range of spindle Speed
    • 50Hz : 80 - 1250rpm
    • 60Hz : 95 - 1500rpm
  • Auto-feeding step of spindle : 6 Steps
  • Auto-feeding amount of spindle : 0.06 - 0.39mm/r
  • Swivel angle of headstock : Plus Minus 45 Degrees
  • Table Size : 800 x 240mm
  • Forward and Backward travel of table : 175mm
  • Left and Right Travel of table : 700mm
  • Motor Power : 1.5kW
  • Gross Weight : 370kg
  • Packing Sizes : 770 x 880 x 1160mm
